MagicLab · Humanoid robots
MagicBot Gen1
Full-size general-purpose humanoid with advanced dexterity for varied industrial tasks
Overview
The MagicBot Gen1 is a 1.74-meter general-purpose humanoid, weighing approximately 70 kg, equipped with 42 degrees of freedom. It features dexterous 6-DoF hands and is positioned for multi-robot collaboration in inspection, material handling, and factory operations.
Specifications
- Deployment Stage
- Piloting
- Degrees of Freedom
- 42 active DoF (neck 2, arms 7 each, hands 11 each, waist 2, legs 6 each)
- Height
- 1,740 mm
- Max Speed
- >=4 km/h (~1.1 m/s)
- Payload Capacity
- Single-arm load up to 7.5 kg; total-body static load up to 40 kg
- Reach
- 800 mm arm reach (shoulder to fingertip)
- Runtime
- 3-5 h operating time (25 Ah / 1.35 kWh battery)
- Weight
- ~70 kg
- Availability Status
- commercially_available
- Compute
- 8-core CPU + 100 TOPS AI processor
Where it performs
- High number of degrees of freedom enables complex movements
- Integrated 6-DoF dexterous hands for fine manipulation
- Designed for multi-robot collaboration in industrial settings
What to check before buying
- Currently in piloting phase, indicating limited commercial availability
- Battery runtime of 3-5 hours may require charging cycles
- Pricing is not publicly listed by the manufacturer
